Diamond Series - MPPT Solar PCU/Hybrid
Inverter
Power your world with affordable Diamond Series Solar PCU – MPPT solutions
Diamond Series - MPPT Solar PCU/Hybrid Inverter
Product Features
- DSP IC based Pure Sine Wave design
- Inbuilt MPPT Charge Controller
- Maximum preference to Solar Power
- USB based monitoring
- 30 days data Logs
- Inbuilt DC and AC energy meter
- Tested as per IEC 61683 and IEC 60068-2-(1,2,14,30) standards
- Robust design - 20 yrs product life
-
AC and DC Parameter configurable from LCD Switches :- AC - Output Voltage/Input Voltage
DC - Charging Voltage/Charging Current - Enable/Disable by LCD Switches - NLSD Grid Charging, IT Load
- Operating Mode - PCU/SMART/HYBRID
- Application - Hospitals, Schools, Home, Industries, Petrol Pumps, Banks, Offices.
Product Range
| S.No. | Model | Weight - kg (Approx) | Dimension LXWXH (mm) |
|---|---|---|---|
| 1 | ADM 3000/48V | 44 | 457X254X457 |
| 2 | ADM 5000/48V | 51 | 457X254X457 |
| 3 | ADM 5000/96V | 71 | 610X330X584 |
| 4 | ADM7500/120V | 80 | 457X254X457 |
| 5 | ADM 10000/120V | 103 | 610X330X660 |
